Rugged and Reliable Encoders
Scancon offers encoder solutions for a variety of equipment and operations in the Mining Industry. Known for its expertise in manufacturing harsh environment encoders, Scancon provides ATEX-certified Stainless Steel encoders for use in both surface and subsurface mining operations.
REXM-A-SR
Stainless Steel - For mining applications| Diameter: | 68 mm | |
| Resolution: | up to 10,000 ppr | |
| Shaft: | ø 10 mm to 11 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| IP rating: | 66 (67 option) | |
| Certification: | Ex db I Mb |
REXM-A-SA
Stainless Steel - For mining applications| Diameter: | 68 mm | |
| Resolution: | up to 10,000 ppr | |
| Shaft: | ø 10 mm to 11 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| IP rating: | 66 (67 option) | |
| Certificates: | Ex db I Mb |
REXM-H-SR
Stainless Steel - For mining applications| Diameter: | 68 mm | |
| Resolution: | up to 10,000 ppr | |
| Hollow Shaft: | ø 10 mm and 16 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| IP rating: | 66 (67 option) | |
| Certificates: | Ex db I Mb |
REXM-H-SA
Stainless Steel - For mining applications| Diameter: | 68 mm | |
| Resolution: | up to 10,000 ppr | |
| Hollow Shaft: | ø 10 mm to 15 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| IP rating: | 66 (67 option) | |
| Certificates: | Ex db I Mb |
SCH86BXM
Stainless Steel - For mining application| Diameter: | 86 mm | |
| Resolution: | up to 10,000 ppr | |
| Hollow Shaft: | Ø 5/8 in to 1 in | |
| Temperature: | -40° C to 70° C (operating) | |
| IP rating: | 65 (66 & 67 options) | |
| Certificates: | Ex db I Mb |
EXME-A SSI
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Shaft: | ø 10 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | SSI | |
| Certifications: | Ex db I Mb |
EXME-A ProfiBus
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Shaft: | ø 10 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | ProfiBus | |
| Certifications: | Ex db I Mb |
EXME-A CANopen
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Shaft: | ø 10 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | CANopen | |
| Certifications: | Ex db I Mb |
EXME-A DeviceNet
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Shaft: | ø 10 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | DeviceNet | |
| Certifications: | Ex db I Mb |
EXME-H SSI
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Hollow Shaft: | ø 14 mm and ø 16 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | SSI | |
| Certifications: | Ex db I Mb |
EXME-H ProfiBus
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Hollow Shaft: | ø 14 mm and ø 16 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | ProfiBus | |
| Certifications: | Ex db I Mb |
EXME-H CANopen
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Hollow Shaft: | ø 14 mm and ø 16 mm | |
| Temperature: | -40° C to 70° C (operating) | |
| Protocol: | CANopen | |
| Certifications: | Ex db I Mb |
EXME-H DeviceNet
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Hollow Shaft: | ø 14 mm and ø 16 mm | |
| Protocol: | DeviceNet | |
| Temperature: | -40° C to 70° C (operating) |
EXMU
| Diameter: | 78 mm | |
| Resolution: | Up to 16 bits (Singleturn) Up to 30 bits (Multiturn) | |
| Hollow Shaft: | ø 10 mm | |
| Protocol: | CANopen | |
| Temperature: | -40° C to 70° C (operating) | |
| Certifications: | MSHA |
