Incremental

Incremental Encoders

Scancon manufactures a full range of incremental encoders ranging in size from ø9 mm to ø115 mm. In addition to offering superior design features, Scancon also offers some of the highest disk resolutions (ppr) in the industry. If you do not see an encoder model for your application, contact us and our Design Engineering group will discuss possible encoder solution options.


Micro Encoders

Diameter: 16 mm to 20 mm
Resolution: up to 5,000 ppr
Shaft : ø 1.5 mm to 1/8 in
Hollow Shaft: ø 1.5 mm to 4 mm

Mini Encoders

Diameter: 24 mm to 41 mm
Resolution: up to 7,500 ppr
Shaft: ø 4 mm to 1/4 in
Hollow Shaft: ø 3 mm to 1/4 in

Standard Encoders

Diameter: 50 mm to 68 mm
Resolution: up to 12,500 ppr
Shaft: ø 6 mm to 11 mm
Hollow Shaft: ø 6 mm to 16 mm

Heavy Duty Encoders

Diameter: 60 mm to 115 mm
Resolution: up to 12,500 ppr
Shaft: ø 6 mm to 15 mm
Hollow Shaft: ø 6 mm to 1 in

Ex-proof Encoders

Diameter: 24 mm to 115 mm
Resolution: up to 10,000 ppr
Shaft: ø 4 mm to 11 mm
Hollow Shaft: ø 2 mm to 1 1/4 in

Ex-proof Encoders - Mining

Diameter: 24 mm to 115 mm
Resolution: up to 10,000 ppr
Shaft: ø 4 mm to 11 mm
Hollow Shaft: ø 2 mm to 1 in

SubSea Encoder

Diameter:: 68 mm
Resolution:: up to 2,048 ppr
Hollow Shaft: ø 10 mm to 1 in
IP rating: IP 68 to 6000 m depth

Stainless Steel

Diameter: 50mm to 115mm
Resolution: up to 12500 ppr
Shaft: ø 6 mm to 11 mm
Hollow Shaft: ø 8 mm to 16 mm
